Mounting Instructions
51
11. Place the door handles on the external square in such a way that
the set screw points in the direction of the strike.
12. Tighten the set screw.
The batteries have been changed. The Door Terminal Basic is ready
for operation again.
Emergency opening via the profile cylinder
An emergency opening of the Door Terminal Basic can be carried
out with a key via the profile cyclinder.
1. Loosen and remove the door handles (see 'Changing the
batteries', Steps 1-2).
2. Remove the cover (see 'Changing the batteries', Steps 3-6).
The profile cylinder is accessible so that the emergency opening can
be carried out.
