Häfele dialock User Manual

Mounting Instructions
27
Scope of delivery
4
3
1
6
5
7
9
2
2
3
10
10
8
8
Door Terminal Basic :
1
1 outer module (fixing plate with bracket and cover)
2
1 set of rosette fittings
3
2 door handles
Small parts bag:
4
1 chipboard screw, 3 x 20
5
1 retaining ring
6
1 pin, 3 x 22
7
1 pin, 4 x 22
8
2 adhesive labels (to assist mounting)
Fastening parts:
9
1 square Spindle
10
4 countersunk screws M4
The length of the fastening parts depend on the thickness of the door
leaf.
