1. Front Ass’y

2. Back Ass’y

3. Strike

4. Strike spacer

5. Card key

9. Installation template

11. Door thickness

(4-1) Dead Bolt Guider : Should remove after finishing installation.

71.8mm (W) x 163.6mm (H) x 18.4mm (D)

154mm (W) x 93mm (H) x 37mm (D)

76mm (W) x 140mm (H) x 28mm (D)

31mm (W) x 140mm (H) x 2mm (D) 1EA

31mm (W) x 140mm (H) x 4.5mm (D) 3EA

4EA

6. Battery

4 pcs (1.5V, "AA" size, LR6 Alkaline)

8. User manual Main user manual

Use for making hole at the door

7. Mounting Plate

77mm (W) x 87mm (H) x 3mm (D)

For 40~50mm

5 x 30mm 2EA : For back cover

5 x 29mm 4EA : For inner upper part

4 x 30mm 12EA : For front/Back plate

4 x 19mm 12EA : For front/Back plate

Including rubber pad

Using for

Height of strike

Including warranty form

TH M5 x 30mm

10. Screw

5 x 60mm 2EA : For back cover TH M5 x 60mm

OH M5 x 29mm

FH T4 x 19mm

FH T4 x 30mm

Name Product specification Remark

Product composition and components

Installation

template

User manual

Häfele ER4800 User Manual
