Haier 1U60IS1ERB User Manual

Indoor Unit
71
Super Match
2.4 Wiring diagram
AC12CS1ERA(S) AC18CS1ERA(S) AC24CS1ERA(S)
TO OUT DOOR
0150507096
2010.12.03
SW1-1
SW1-7 SW1-8 TYPE DEFINE
OFF OFF Cassette OFF ON Convertible(≤24000BTU) ON OFF Duct ON ON Convertible(＞24000BTU)
SW1-2 SW1-3
BTU
B:BLACK
R:RED
W:WHITE
Y/G:YELLOW/GREEN
TEMP.
SENSOR
ROOM
SENSOR
PIPING TEMP.
REMOTE
RECEIVER
FLOAT SWITCH
CN5
TR
HEATER
PUMP
SWING
FAN
LEFT/ RIGHT
UP/ DOWN
CN9
CN8
CN7CN11
PANNEL
REMOTE CENTRAL
CN3
CN1
CN29
CN20 CN18
CN21 CN13 CN12
ON
CN14
CN15
CN10
CN19
T3.15A/250VAC
FUSE
87654321
4321
ON
SW1
SW2
Wired
Remote
Controller
RC
2
1
3
B
W
R
Y/G
OFF OFF OFF
ON OFF OFF
OFF ON OFF
ON ON OFF
OFF OFF ON
ON OFF ON
OFF ON ON
ON ON ON
7000 9000 12000 14000 18000 24000 28000 36000
NOTE1.DASHED PART ARE OPTIONAL.
2.
USER SHOULD NOT TO SET SW1 AND SW2.
CH3
CH4
CH5
OFF
OFF OFF OFF
SW1-4
SW1-5 SW1-6
OFF
OFF OFF OFF
ON ON
OFF ON
