Indoor Unit
11
Super Match
1.2 Specication
Item Model AB09CS1ERA (S)
Function —— Cooling Heating
Capacity W 2600 2900
Censible heat ratio W 0.71 /
Dehumidifying capacity 10-³xm³/h 1.0
indoor unit
power supply 1PH, 220-230V~, 50/60Hz
Fan
Type × Number —— centrifugal*1
Speed(H-M-L) r/min 690/620/560
Fan motor output/input
power
W 10/33
Air-ows (H/M/L) m³/h 620/520/450
Speed (Hi/Me/Lo) rpm 700/640/580
Heat exchanger
Type / Diameter mm inner grooved pipe/
￠
7.0
Row —— 1
Total area m² 0.272
Temp.scope
℃
2.0-7.0
Dimension
(LxWxH)
External mmxmmxmm 570*570*260
Package mmxmmxmm 718*680*380
Drainage pipe (material,I.D/O.D) mm PVC 26/32
Control type(Remote/Wired) Remote or Wired
Fresh air hole dimension mm 95
Electricity Heater kW none
Noise level(H-
M-L)
Sound power level dB(A) 50
Sound pressure level dB(A) 40/36/32
weight(Net/Shipping) kg/kg 17/20
panel
panel model(color) PB-700IB(White)
Dimension
External(L*W*H) mmxmmxmm 700*700*60
Package(L*W*H) mmxmmxmm 740*750*115
Weight(Net/Shipping) kg/kg 2.8/4.8
Piping
Refrigerant Type R410A
Pipe
Liquid mm Φ6.35(1/4)
Gas mm Φ9.52(3/8)
Connecting method Flared
