Haier 1U60IS2ERB User Manual

Outdoor Unit
237
Super Match
Item Model 5U45LS1ERA
Function —— Cooling Heating
Rating capacity W 12200 12680
Cooling Pdesign W 12200
Heating pdesign(-10
℃
) W 9000
Rated power input (indoor + outdoor) W 3631 3251
Rated current input (indoor + outdoor) A 15.8 14.1
EER / COP W/W 3.36 3.9
SEER / SCOP W/W 7.0 3.8
Minimum capacity W 1500 1800
Minimum power input W 550 550
Maximum capacity W 13400 14000
Maximum power input (indoor + outdoor) W 5500 5500
Power source —— 1PH, 220-230V~, 50/60Hz
Max. running current (indoor + outdoor) A / A 23.9 23.9
Power facor(under rating power input) —— 99% 99%
Starting current A 5
Fuse size (recommended size) A None
Outdoor unit
Compressor
Model / Manufacture —— TNB306FPGMC/MITSUBISHI
Oil charge and type —— 870CC/ FV50S
Type —— Twin Rotary (DC inverter)
Number —— 1
Fan
Type × Number —— Axial × 1
Speed r/min High 820
Motor output/input power W 126/158
Air-ows (H/M/L) m³/h about 4200
Heat exchanger
Type / Diameter mm TP2M/Φ7.94
row —— 2
Face area m² about 0.78
Dimension
(WxDxH)
External mm 1008×447×830
Package mm 11 3 0× 4 9 0× 1 0 00
Refrigerant control method —— PMVs
Defrosting method —— Automatic by reversible cycle
Crankcase heater power W none
Noise level
Sound power level dB(A) 71
Sound pressure level dB(A) 60
Weight Net / Shipping kg / kg 90/101
Piping
Refrigerant
Type / Charge kg R410A / 3.2
No need to recharge m 40
Recharge g/m 28
Pipe
Liquid mm 5* Φ6.35
Gas mm 3* Φ9.52+2*Φ12.7
Connecting method —— Flared
Between I.D &O.D
Drop between IU & OU m ≤7.5
Piping length between IU & OU m ≤10
Total liquid piping length m ≤40
Drop between indoor units m ≤1
Max. drop between IU &OU m 15
Max. drop between indoor units m 5
Max. piping length between IU & OU m 25
Max. total length m 100
Working temperature
Cooling
℃
-10~46
Heating
℃
-15~24
Tdisignh
：
-10
℃
Tbivalent
：
-7
℃
TOL
：
-15
℃
Pto
：
16W Psb
：
16W Pck
：
0W Poff
：
0W
Cooling
A
（
Cap/EER
）
12666W/3.62
Heating
A
（
Cap/COP
）
7556W/2.35 To l
（
Cap/COP
）
6010W/2.45
B
（
Cap/EER
）
9708W/6.07 B
（
Cap/COP
）
5809W/3.66 Tb
（
Cap/COP
）
7556W/2.35
C
（
Cap/EER
）
5793W/9.2 C
（
Cap/COP
）
3388W/4.62 Cd
（
cooling
）
0.25
D
（
Cap/EER
）
5884W/11.77 D
（
Cap/COP
）
3898W/6.29 Cd
（
heating
）
0.25
Max. cooling condition
Indoor temperature
：
32
℃
/23
℃
Max. heating condition
Indoor temperature
：
27
℃
/-
℃
Outdoor temperature
：
46
℃
/-
℃
Outdoor temperature
：
24
℃
/18
℃
kWh/annum 500 kWh/annum-average 2836 kWh/annum-warm
1. The above performance data are from the combination of 5U45HS1ERA+2*AD09SS1ERA+AD12SS1ERA+AD18SS1ERA.
2. Large drop and long piping installation will obviously reduce the total capacity.
