63
Smart Power
Item Model ADH125H1ERG/1UH125P1ERG
Function cooling heating
Capacity kW 12.5(3.5~15.0) 14.0(4~18.0)
Sensible heat ratio 0.74
Total power input kW 3.57(1.0-6.5) 3.88(1.0-6.5)
Max. power input W 6500 6500
AEER or ACOP 3.45 3.56
Dehumidifying capacity 10
-3
×m
3
/h 4.9
Power cable /
Power source N, V, Hz 1ph, 220~240, 50/60
Running/Max. Running current A/A
16.5(8.7-30.0)/30A 17.5(8.7-30.0)/30A
Start current A /
Circuit breaker A
Indoor
unit
Unit model (color)
Fan
Type × Number
Speed(H-M-L) r/min
Fan motor input power kW
Fan motor output power kW
1Ph, 40A（from outdoor）
ADH125H1ERG
CENTRIFUGALX2
1050/1060/980/900±50r/min(50Pa)
0.275*2
0.22*2
Air-ow(H-M-L) m³/h
3250/2750/2250/1750(37Pa-210Pa)
Heat
exchanger
Type/Diameter mm Inner grooved pipe/φ7.0
Total area m
2
0.45
Dimension
External (L×W×H) mm×mm×mm 1350/490/425(not including ange)
Package (L×W×H) mm×mm×mm
1565/724/510
Drainage pipe (material, I.D./O.D.) mm
none
Controller (O-Optional, S-Standard)
Wired YR-E17(S)
Infrared YR-HBS01(O)
Fresh air hole dimension mm /
Electricity heater kW 0
Sound power dB (A) 61
Sound pressure noise level (H-M-L) dB (A) 47/44/42/39
Weight (Net / Shipping) kg / kg 61/72
Piping
Refrigerant
Type / Charge g R410A/3700
Recharge quantity g/m 45
Pipe
Liquid mm 9.52
Gas mm 15.88
Between
I.D&O.D
MAX.Drop m 30
MAX.Piping length m 75
Norminal condition:
Indoor temperature (cooling): 27DB(°C)/19WB(°C), indoor temperature (heating): 20DB(°C)
Outdoor temperature(cooling): 35DB(°C)/24WB(°C), outdoor temperature(heating): 7DB(°C)/6WB(°C)
The noise level will be measured in the third octave band limited values, using a Real Time Analyser calibrated sound intensity
meter. It is a sound pressure noise level.
