62
Smart Power
2. Specication
Item Model ADH105H1ERG/1UH105N1ERG
Function cooling heating
Capacity kW 10.5(2.5~11.0) 11.5(2.5~12.0)
Sensible heat ratio 0.74
Total power input kW 3.00(0.5~5.3) 3.10(0.5~5.3)
Max. power input W 5300 5300
AEER or ACOP 3.46 3.66
Dehumidifying capacity 10
-3
×m
3
/h 3.2
Power cable /
Power source N, V, Hz 1ph, 220~240, 50/60
Running/Max. Running current A/A
13.3(2.3-23.2)/23.2A 13.7(2.3-23.2)/23.2A
Start current A /
Circuit breaker A
Indoor
unit
Unit model (color)
Fan
Type × Number
Speed(H-M-L) r/min
Fan motor input power kW
Fan motor output power kW
1Ph, 40A（from outdoor）
ADH105H1ERG
CENTRIFUGALX2
850/790/730/720±50r/min(37Pa)
0.27*2
0.17*2
Air-ow(H-M-L) m³/h
2880/2380/1880/1380
External Static Pressure pa (37Pa-210Pa)
Heat
exchanger
Type/Diameter mm Inner grooved pipe/φ7.0
Total area m
2
0.45
Dimension
External (L×W×H) mm×mm×mm 1350/490/425
Package (L×W×H) mm×mm×mm 1565/724/510
Drainage pipe (material, I.D./O.D.) mm
PVC
Controller (O-Optional, S-Standard)
Wired YR-E17(S)
Infrared YR-HBS01(O)
Fresh air hole dimension mm /
Electricity heater kW 0
Sound power dB (A) 59
Sound pressure noise level (H-M-L) dB (A) 45/41/37/33
Weight (Net / Shipping) kg / kg 59/70
Piping
Refrigerant
Type / Charge g R410A/2500
Recharge quantity g/m 45
Pipe
Liquid mm 9.52
Gas mm 15.88
Between
I.D&O.D
MAX.Drop m 30
MAX.Piping length m 50
Norminal condition:
Indoor temperature (cooling): 27DB(°C)/19WB(°C), indoor temperature (heating): 20DB(°C)
Outdoor temperature(cooling): 35DB(°C)/24WB(°C), outdoor temperature(heating): 7DB(°C)/6WB(°C)
The noise level will be measured in the third octave band limited values, using a Real Time Analyser calibrated sound intensity
meter. It is a sound pressure noise level.
