MEDIUM STATIC DUCTED (PRO SERIES) TECHNICAL OVERVIEW
H9
ENGLISH
DIP Switch Settings
Description SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8
AM24LP2VHA ON ON OFF --- --- --- --- ---
Room card invalid(default) --- --- --- OFF --- --- --- ---
Room card valid --- --- --- ON --- --- --- ---
Cool and heat(default) --- --- --- --- OFF --- --- ---
Cool only --- --- --- --- ON --- --- ---
External alarm
output(default)
--- --- --- --- --- OFF --- ---
Fresh air --- --- --- --- --- ON --- ---
Without filter clean remind
(default)
--- --- --- --- --- --- OFF ---
With filter clean remind --- --- --- --- --- --- ON ---
ESP DUCT ( USA) --- --- --- --- --- --- OFF 0
EU. & Australia --- --- --- --- --- --- --- ON
Indoor unit Address
(Indoor unit address for one wired
controller control more than one unit)
SW3-5 SW3-6 SW3-7 SW3-8
0 (master) OFF OFF OFF OFF
1 (slave) OFF OFF OFF ON
2 (slave) OFF OFF ON OFF
3 (slave) OFF OFF ON ON
4 (slave) OFF ON OFF OFF
5 (slave) OFF ON OFF ON
6 (slave) OFF ON ON OFF
7 (slave) OFF ON ON ON
8 (slave) ON OFF OFF OFF
9 (slave) ON OFF OFF ON
10 (slave) ON OFF ON OFF
11 (slave) ON OFF ON ON
12 (slave) ON ON OFF OFF
13 (slave) ON ON OFF ON
14 (slave) ON ON ON OFF
15 (slave) ON ON ON ON
