SERVICE MANUAL
Model: BFQ50
10
Issue 2012-12-27
Rev.
Ref1212S006V0
4-3. Control panel assembly (Panel, cover board, knob, indicator light)
Unscrew the compartment grill (refer 4-2), push the panel claw gently with our finger or tools, at the
same time pull panel outside then take away it.
Take away the knob with a sharp-edged tool.
Press the cover board and take it away.
Press two claws on indicator light side and push it from back to front.
