Remove the eight screw indicated on the
4-5 Remove the power module
ķ Remove the four screw indicated on the
figure above by ƻ
ĸ Then remove the power module
4-6 Remove the Main board
ķ
figure above by
Remove the Main board
4-7 Remove the remote control
Remove the one screw, take out the remote
control board
ĸ
ƻ
4-8 Remove the keypad control
Remove the two screw indicated on the figure
above by blue line.
Then remove the keypad module.
ĸ
