Haier HL42XK1 User Manual

Pin number Signal number
1 GND
2 ADIN1-K0
3 ADIN2-K1
Speaker connector(CNC1)
Pin number Signal number
1 SPEA_L+
2 SPEA_L-
3 SPEA_R_
4 SPEA_R+
Other connectors:
CNB2 to Upgrade the program of MTK5380L (U13) AND FLASH (U17)
3-3. Power Board
3-3-1 Function Description:
Supply power for Main board, Panel.
3-3-2Connectordefinition
CON2

Haier HL42XK1 Specifications

General

Brand	Haier
Model	HL42XK1
Category	TV
Language	English
