Haier HL42XK1 User Manual

Power connectors (CNA1)
A Board Main Board
B Board Power Board
3-1 Board Location
No. Parts number Description
3-2 Main Board & AV Board
3-2-1 Function Description:
Main Board˖
Process signal which incept from exterior equipmentˈthen translate into signal that panel can
display.
3-2-2 Connector definition
Main board connector

Haier HL42XK1 Specifications

General

Brand	Haier
Model	HL42XK1
Category	TV
Language	English
