10
2. The hose couplers are color coded to assist you in making the proper
connections. You may want to use gray for cold and red for hot. Thread the inlet
hoses onto the water faucets by hand until snug. Then using pliers, tighten an
additional two-thirds turn.
IMPORTANT: To avoid damage to the hose couplings, do not overtighten.
NOTE: To avoid damage to the faucets do not use plumber’s tape or sealants on
the valve threads.
3. Thread the other end of the inlet hoses by hand onto the inlet valves marked
“H” (hot) and “C” (cold) on the back of the washer until snug. Then using pliers,
tighten an additional two-thirds turn.
IMPORTANT: To avoid damage to the hose couplings, do not overtighten.
NOTE: To avoid damage to the washer inlet valves, do not use plumber’s tape or
sealants on the valve threads.
4. Turn on the hot and cold water faucets and check for leaks. If there is any leaking,
check steps 1 through 3 again.

Haier HLP24E Specifications

General

Door hinge	Up
Drum volume	42.4 L
Control type	Buttons
Display type	LED
Loading type	Top-load
Drum material	Stainless steel
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
AC input voltage	120 V
AC input frequency	60 Hz
Energy consumption washing per cycle	- kWh
Drum capacity	- kg
Spin-drying class	-
Maximum spin speed	800 RPM
Noise level (spin)	- dB
Load balancing system	No
Number of washing programs	3

Weight and Dimensions

Depth	510 mm
Width	500 mm
Height	901.7 mm
Weight	19504 g
