EN
2-Product description
7
2.1 Picture of appliance
Front (Fig. 2-1):
Stain removal
Delay
Temp.
Wool
Spin
Smar t
Shirt
Quick 1 5’
Cotton
Remote
Babyc are
Synthetic s
Eco 4 0-60
Cotton 2 0°C
Delicate
Allergy c are
Refre sh
REFRESH
525 DRUM
Auto Dose
Extra Rins e
Speed
1
2
3 4 5
6
T1
T2
T3
T4
Note: Deviations
Due to technical changes and diff erent models, the illustrations in the following chap-
ters may diff er from your model.
1 Detergent / Softener drawer
2 Worktop
3 Control panel
4 Door
5 Filter cover
6 Adjustable feet
1 Transportation bolts (T1-T4)
2 Backcover
3 Backcover screws(9EA)
4 Power cord
5 Drain hose
6 Water inlet valve
2-1 2-2
Rear side (Fig. 2-2):
2.2 Accessories
Check the accessories and literature in accordance with this list (Fig.:2.3):
Inlet hose Blanking plugs
Drain hose bracket
Noise
reduction pads
User manual
Warranty card
2-3
2x
2x
