Haier HW90-B1439 User Manual

3-Control panel
EN
When the function is activated the temperature of the programme cannot be changed.
If “Temp.” button is pushed the “Steam” function will be deactivated. You can activate
“Steam” function only before to start any programme. You cannot activate “Steam” func-
tion while the appliance is already executing a programme.
!"!9#$%&'()*&#+%((*&4:;(<8#<)&,14
Press this button (Fig. 3-5-4) to rinse the laundry more
times with fresh water. This is recommended for peo-
ple with sensitive skin.
By pressing the button several times one to three addi-
tional cycles can be selected. They appear in the display
with !!"/ !!#/ !!$.
!"!"#$%&'()*&#453116#%34
This function saves time and energy. Preferable if laun-
dry is slightly soiled. Press simultaneously button “Extra
rinse.“ and ”Delay” (Fig. 3-5-5) for about 3 seconds to
activate the “Speed up” function; % &&'(u is displayed.
This function is not available in all programmes (see
PROGRAMMES).
!=#4>1?8@7#+%((*&
Press this button (Fig. 3-6) to start the programme with
a delay. End time delay could be increased in steps of
FG";%):&-#"31+;"GHI2JK(7"L+1"-M.;/0-"=%#/0.!"+,"):$*
means end of programme cycle will be in 6 hours and
30 minutes. Press “Start/Pause” button to activate the
time delay. It is not applicable to programme SPIN.
3-5-4
3-6
3-5-5
3-6
3-6
3-8-2
3-8-1
3-7
Press this button (Fig. 3-7) gently to start or inter-
Press button "Temp." and "Steam" (Fig. 3-8-1) for 3
The display shows (Fig. 3-8-2) if a button will be
10
-

Haier HW90-B1439 Specifications

General

Door color	Black
Door hinge	Left
Motor type	Beltless
Control type	Rotary, Touch
Display type	LED
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Current	10 A
Connected load	2000 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	0.26 W
Power consumption (standby)	0.28 W
Energy consumption washing per cycle	0.52 kWh
Washing class	A
Annual water consumption washing	9500 L
Annual energy consumption washing	122 kWh
Drum capacity	9 kg
Cycle time (max)	275 min
Wi-Fi controlled	No
Residual moisture	53 %
Spin-drying class	B
Maximum spin speed	1400 RPM
Minimum spin speed	400 RPM
Noise level (spin)	67 dB
Noise level (wash)	53 dB
Number of washing programs	16
Add garment (pause) function	-
Cycle time (quick washing program)	15 min
Package depth	695 mm
Package width	650 mm
Package height	890 mm
Package weight	77000 g

Weight and Dimensions

Depth	600 mm
Width	595 mm
Height	850 mm
Weight	74000 g
Door diameter	320 mm
