Haier HW90-B1439 User Manual

8.1 Cleaning the detergent drawer
Take always care there are no detergent residues.
Clean the drawer regularly (Fig. 8-1):
1. Pull out the drawer until it stops.
2. Press the release button and remove the drawer.
3. Flush the drawer with water until it is clean and
insert the drawer back in the appliance.
8.2 Cleaning the machine
▶ @/5.1*$&!($40#!"/($)1+"/*$#.(0/"/*$0/)$40"/&(-
nance.
▶ @'($0$',-&$#.,&!$ "&!$',05$."T1")$&,$#.(0/$&!($40-
chine case (Fig. 8-2) and rubber components.
▶ Do not use organic chemicals or corrosive sol-
vents.
Note: Hygiene
For regular maintenance we recommend to run programme HYGIENIC with no load in
order to remove possible corruptive residues quarterly. It is better to use a small
amount of special machine cleaner in washing agent compartment (2).
B!#$C*'+-$(6A+'$)*A)+$*6.$(6A+'$)*A)+$DA'+-
To prevent blockage of water supply by solid substanc-
('$."U($."4($#.(0/$+(*1.0+.2$&!($"/.(&$N0.N($%.&(+?
▶ @/5.1*$ &!($ 5, (+$ #,+)$ 0/)$ &1+/$ ,>$ &!($ 0&(+$
supply.
▶ @/'#+( $ &!($ 0&(+$ "/.(&$ !,'($ 0&$ &!($ G0#U$ LV"*?$
8-3) of the appliance as well as on the tap.
▶ V.1'!$&!($%.&(+'$ "&!$ 0&(+$0/)$0$G+1'!$LV"*?$WXYM?
▶ 9/'(+&$&!($%.&(+$0/)$"/'&0..$&!($"/.(&$!,'(?$
8.4 Cleaning the drum
▶ Remove accidentally washed metal parts such as
pins, coins, etc. from the drum (Fig. 8-5) because
they cause rust stains and damage.
▶ @'($0$/,/X#!.,+")($#.(0/(+$-,+$+(4,N"/*$+1'&$
stains. Observe the warning hints of the cleaning
agent manufacturer.
▶ Do not use any hard objects or steel wool for
cleaning.
8-3 8-4
8-5
8-1
1
2
8-2
EN
8-Care and cleaning
19

Haier HW90-B1439 Specifications

General

Door color	Black
Door hinge	Left
Motor type	Beltless
Control type	Rotary, Touch
Display type	LED
Loading type	Front-load
Product color	White
Built-in display	Yes
Appliance placement	Freestanding
Current	10 A
Connected load	2000 W
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	0.26 W
Power consumption (standby)	0.28 W
Energy consumption washing per cycle	0.52 kWh
Washing class	A
Annual water consumption washing	9500 L
Annual energy consumption washing	122 kWh
Drum capacity	9 kg
Cycle time (max)	275 min
Wi-Fi controlled	No
Residual moisture	53 %
Spin-drying class	B
Maximum spin speed	1400 RPM
Minimum spin speed	400 RPM
Noise level (spin)	67 dB
Noise level (wash)	53 dB
Number of washing programs	16
Add garment (pause) function	-
Cycle time (quick washing program)	15 min
Package depth	695 mm
Package width	650 mm
Package height	890 mm
Package weight	77000 g

Weight and Dimensions

Depth	600 mm
Width	595 mm
Height	850 mm
Weight	74000 g
Door diameter	320 mm
