GB
11-Technical data
29
HW100 HW90 HW80
Voltage in V 220-240 V~/50Hz
Current in A 10
Max power in W 1900
Water pressure in MPa 0.03≤P ≤1
Netto weight in kg 74 7274
11.1 Additional technical data
11.3 Standards and Directives
This product meets the requirements of all applicable EC directives with the correspon-
ding harmonised standards, which provide for CE marking.
Note: The exact height of your washer is dependent on how far the feet are extended from
the base of the machine. The space where you install your washer needs to be at least
40mm wider and 20mm deeper than its dimensions.
TOP VIEWWallFRONT VIEW
A
B
E
D
C
HW100 HW90 HW80PRODUCT DIMENSIONS
B Overall width of product mm
A Overall height of product mm
C Overall depth of product
(To main control board size) mm
D Depth of door open mm
E Minimum door clearance
to adjacent wall mm
11.2 Product dimensions
850 850 850
595 595 595
600 600 550
1100 1100 1050
400 400 400
