Haier L32A2120 User Manual

-9-
INSTALLATION
AV EQUIPMENT
There are two HDMI ports located on the back of your TV. You can connect a Blu-ray player, DVD player, or other video
equipment through these ports.
There is one component (Y, Pb, Pr) and composite (AV) video input located on the back of your TV. You can connect
a VCR, cable box, or other video equipment to these jacks.
Please see the diagram below. You may also need to refer to the owner's manual of the device that you are trying to connect.
one
To audio outputs
VIDEO EQUIPMENT
TO VIDEO
output
Yellow (video)
White(audio L)
Red(audio R or Pr)
Y
W
R
W
R
W R
W R
G
B
R
G
R
B
Blue(Pb)
Green(Y)
B
G
VIDEO EQUIPMENT with YPbPr
W
R
HDMI
VIDE O
L
R
AV2
USB
The television's inputs can be connected to the following types of equipment: VCR, multi disc player, DVD, camcorder,
video game or stereo system, etc.....
There is a composite (AV) video input and a USB port located on the side of the TV. You can use this AV input to
conveniently connect devices that you may frequently connect and disconnect, such as a camcorder.
HDMI 1
AC INPU T
100-2 40V ~5 0/6 0Hz
L
R
AV1
Pr
Y
Pb
HEADPHONE
PC AUD IO
INP UT
COA XIAL
RF INPU T
COM PONEN T
INP UT
AUD IO
INP UT
VGA INPU T
HDMI 2
