Connection wire(Blacklight )
Service Manual
Model No.:
7-3 .Wiring Connection Diagram
NO. Name
1
2
3
4
5
Connection Wire(For Keyboard and Remote)
Connection Wire(For Speaker)
LVDS Wire
Connection Wire(Power Wire)
5
2
3
4
1
