Haier LE32B8500T User Manual

INSTALLATIONCAUTION
*Locate the TV in the room where light does
not strike the screen directly.
*Total darkness or a reflection on the picture
screen can cause eyestrain. Soft and indirect
lighting is recommended for comfortable
viewing.
*Allow enough space between the TV and the
wall to permit ventilation.
*Avoid excessively warm locations to prevent
possible damage to the cabinet or premature
component failure.
*Do not cover the ventilation openings when
using theTV.
Main parameter
Main features
4 NICAM；
5 T ；ime-shift
3
HDMI interface and SCART
Interface；
High luminance, wide viewing
angle；
2
Used as Television, display terminal,
PC display；
1
Never tamper with any components inside the
TV, or any other adjustment controls not
described in this manual. All LED-TV's are high
voltage electrical equipment.
When you clean dust or any water drops off the
SCREEN or CABINET or around any of the
buttons or connectors, the power cabled should
be removed from the power socket. Wipe the TV
with a soft, dry, dust free cloth.
During thunderstorms, unplug the power cable
and aerial / antenna cable to prevent damage to
your TV and any other devices connected to it.
All repairs to this TV should only be performed
by qualified TV service
personnel.
02 Introdution
Introduction
Panel
PAL-B/G , I , D/K
PAL/SECAM/MPEG2/MPEG4/H.264
AC 100
-
240 V 50/60Hz
Analog RGB(PC) x1; PC audio x1
High-Definition Multimedia Interface (HDMI) x 2
Composite Input x 1
YPbPr x 1
SCART Inputx 1
45W
CI x 1
USB x 1
RF Co-Ax x 1
Composite video input >=350
YPbPr >=400
Headphone x 1
TV System
Video Signal System
Input Power Voltage
Power consumption
Standby Power consumption
Audio Output Power(THD ≤ 7%)
Signal Input
Signal output
Horizontal definition (TV line)
SECAM-B/G , D/K , L ,
≤0.50W
DVB-T, DVB-C,DVB-T2
500(DTV);100(ATV)Storage channel number
SCART Output x 1
COAXIAL Output x 1
2x8W
32"
High-Definition Multimedia Interface (HDMI) x 3(only for 42")
72W
2x8W
≤0.50W
42"
05

Haier LE32B8500T Specifications

General

Brand	Haier
Model	LE32B8500T
Category	LCD TV
Language	English

Summary

Safety Warnings

Safety Notices and Environmental Responsibility

Electrical Safety and Servicing

Safety Warnings

General Warning and Caution Scenarios

Presents visual warnings and cautions regarding electrical safety, handling, and ventilation.

Introduction

TV Connectivity Options and Setup

Details connection options like SCART, HDMI, AV, Component, VGA, and USB with setup steps.

Remote Control

Remote Control Button Functions

Lists and describes the functions of each button on the remote control.

OPERATION

Initial Setup: Installation Guide and Mode Selection

Guides the user through initial setup, including language and mode selection.

Operation

Channel Tuning: Auto DVB-T

Details the steps for performing an automatic channel scan for DVB-T.

Channel Tuning: Auto DVB-C and DTV Manual DVB-T

Details auto tuning for DVB-C and manual tuning for DTV (DVB-T).

Manual Tuning and Program Editing

PVR Function: Recording and Playback

Operation

Power Management, Lock Menu, and EPG

PVR Recording and Reminders

Operation

PVR Function: Preparation and Formatting

Details preparing and formatting USB devices for PVR functionality.

Timeshift Functionality

Explains the timeshift function for pausing and resuming programs.

USB Media Player Usage

Explains how to access and use the USB player for various media types.

Operation

Timeshift Feature Limitations

Trouble shooting

Common Picture and Audio Issues

Lists common picture and audio problems with their corresponding inspection checks.

Trouble Shooting

PC and External Device Connectivity Issues

Trouble Shooting

Digital TV Reception and Cable Problems

Specification

32-inch HD Ready TV Specifications

Lists detailed specifications for the 32" HD Ready TV model.

42-inch Full HD TV Specifications

Lists detailed specifications for the 42" Full HD TV model.
