130
Before installation , be sure to remove the plug .When the valve box is connected with the outdoor unit, the left
side of the three pipes or the right side of the three pipes can be selected according to the actual installation
requirements. At the same time, the other end of the three tubes needs to be blocked.
HP gas Pipe (Ø28.58)
Suction gas Pipe (Ø28.58)
Gas Pipe (Ø15.88)
Plug
Plug
Liquid Pipe (Ø15.88)
Liquid Pipe (Ø9.52)
5. Installation
