223
6. Sensor resistance table
NO. Model Name Code Characteristic
1
AV08IMVURA
AV10IMVURA
AV12IMVURA
AV14IMVURA
AV16IMVURA
AV18IMVURA
AV20IMVURA
AV22IMVURA
Tao sensor 0150401910 R25=10KΩ
2 Td1sensor 0150401914 R80=50KΩ
3 Td2 sensor 0150401915 R80=50KΩ
4 Toci1/Tsacc sensor 0150401911 R25=10KΩ
5 Tdef sensor 0150401913 R25=10KΩ
6 Toil1sensor 0150401916 R80=50KΩ
7 Toil2sensor 0150401917 R80=50KΩ
