50
＞1000
＞300
＞300
Back
Left
Right
Front
＞300
①
② ③ ④
⑤
⑥
⑦
⑧
980
1690
750
100
100
630
80
80
755
800
.
Space between fixing holes 755
.
Space between fixing holes 800
Unit:mm
155
822
Air outlet
duct
connection
position
122
198
70
AV08/10/12/14IMVURA
No. Name Remark
1 Signal line hole(Ø25) Using the rubber plug in the unit's attachment for protection
2 Pipe outlet for 2-pipe system
3 Pipe outlet for 3-pipe system
4 Power supply hole
hole,and using the line sheath in the unit's attachment for
protectionAccording to the wire diameter size to choose the
appropriate line
5 Hoisting hole
6 Power supply of signal line hole
7 Refrigerant pipe outlet
8 Drain hole
3. Dimension
