(8)
Indicator FRZ.: lights up when the
freezing temperature is being dis-
played
(9)
Indicator
: lights up, if the sensor
buttons are unlocked.
(10)
Indicator
KEEP COOL
(11)
Indicator
DRINK
(12) Indicator
FRUIT
(13) Sensor button LOCK/UNLOCK
(14)
Sensor button VARIO TEMP. for set-
ting the functions ‘KEEP COOL’,
‘DRINK’ or ‘FRUIT’
(15)
Sensor button
for adjusting the
temperature downwards in the refrig-
erator/freezer
(16)
Sensor button TEMP. SELECT to
select the temperature setting range
(17)
Sensor button
for adjusting the
temperature upwards in the refrigera-
tor/freezer
(18)
Indicator
for Super Freeze mode
(19) Temperature indicator
(20)
Indicator REF.: lights up when the
cooling temperature is being shown
Display and operating field
Hold 3sec. Unlock
FRZ.REF.
°C
(8)
(13)
(16)
(17)
(18)
(19)
(15)
(14)
(12)
(11)
(10)
(9)
(20)
Appliance components/operating elementsPage EN-12
