9. Measure the distance from each speaker to the listening position, and write it down.
(Even if all of your speakers are the same distance from the listening position, you will
need to do this.)
10. Enter the distance that you measured from each speaker to the listening position.
Select a speaker, then use the Left/Right buttons to change the measurement.
You can enter distances between 0 and 30 feet (9.1m). The default distance for all
speakers is 10 feet (3m).
• If you want to use metric measurements, select “Unit” and use the Left/Right buttons
to change the units to meters.
11. When you’re nished, press the OSD/Menu button to exit the menu system.
Assign Connectors to the AVR’s Source Buttons
1. Review the input connections you listed on the Source Buttons and Assigned
Connectors table, on page 5. Note what changes (if any) you want to make from the
default connector assignments that appear on the list.
2. Turn on your TV and select the TV input where you connected the AVR in Connect Your
TV or Video Display, on page 4.
3. Press the remote control’s OSD/Menu button. The AVR’s on-screen display (OSD) setup
menu will appear on the TV. (Note: If you have used a composite video connection to
your TV, the OSD menus will not appear on your TV. Follow the steps below using the
AVR’s front-panel display.)
MASTER MENU
Source Select
Source Setup
Surround Mode
Speaker Setup
Zone2
Network
System Setup
4. Use the remote’s arrow and OK buttons to select “Source Setup,” and use the left/right
arrow buttons to select a source button with connectors that you want to re-assign.
Source Setup
Source
Title
Video In
Audio In
Tone
Bass
Treble
Night Mode
Lip Sync
Disc
HDMI 2
HDMI 2
OFF
0
0
OFF
0mS
5. Select “Video In” and select the video input connector you want to assign to the source
button. Press the OK button. NOTE: If you select an HDMI connector as the video input
connector, the audio input connector will automatically change to the same HDMI
connector. You cannot use a different audio input connector with an HDMI video input
connector.
Source Setup
Source
Title
Video In
Audio In
Tone
Bass
Treble
Night Mode
Lip Sync
Disc
HDMI 3
HDMI 3
OFF
0
0
OFF
0mS
6. If you have not selected an HDMI connector for Video In, select “Audio In” and select
the audio input connector you want to assign to the source button. Press the OK button.
Source Setup
Source
Title
Video In
Audio In
Tone
Bass
Treble
Night Mode
Lip Sync
Disc
Composite 1
Optical 1
OFF
0
0
OFF
0mS
7. Press the remote’s Back/Exit button and repeat steps 3 – 6 for the remaining source
buttons with connectors you want to re-assign.
You are now ready to enjoy your AVR!
IMPORTANT: For complete information about using all of your audio/video
AVR’s features and capabilities, download the AVR 1710, AVR 171/230,
AVR 171/230C, AVR 1610, AVR 161/230, AVR 161/230C Owner’s Manual
or the AVR 1510, AVR 151/230, AVR 151/230C Owner’s Manual from
www.harmankardon.com.
General Specifications
Power consumption
(AVR 1710/AVR 171):
(AVR 1610/AVR 161):
(AVR 1510/AVR 151):
<0.5W (standby); 510W (maximum)
<0.5W (standby); 450W (maximum)
<0.5W (standby); 410W (maximum)
Dimensions (W x H x D): 17-5/16" x 4-3/4" x 11-13/16"
(440mm x 121mm x 300mm)
Weight
(AVR 1710/AVR 171):
(AVR 1610/AVR 161):
(AVR 1510/AVR 151):
11 lb (5.1kg)
10 lb (4.6kg)
10 lb (4.6kg)

Harman Kardon AVR 1610 Specifications

Audio Specifications

stereo power	85W per channel, two channels driven @ 6/8 ohms, 20Hz – 20kHz, <0.1% THD
multichannel power	85W per channel, two channels driven @ 6/8 ohms, 20Hz – 20kHz, <0.1% THD
input sensitivity/impedance	250mV/27k ohms
signal-to-noise ratio (IHF-A)	100dB
surround system adjacent channel separation (Dolby Pro Logic/DPLII)	40dB
surround system adjacent channel separation (Dolby Digital)	55dB
surround system adjacent channel separation (DTS)	55dB
frequency response (@1W)	10Hz – 130kHz (+0dB/–3dB)
high instantaneous current capability (HCC)	±29 amps
slew rate	40V/sec

FM Tuner Specifications

frequency range	87.5MHz – 108.0MHz
usable sensitivity IHF	1.3µV/13.2dBf
signal-to-noise ratio (mono/stereo)	70dB/68dB
distortion (mono/stereo)	0.2%/0.3%
stereo separation	40dB @1kHz
selectivity (±400kHz)	70dB
image rejection	80dB
IF rejection	80dB

AM Tuner Specifications

frequency range	520kHz – 1, 610kHz
signal-to-noise ratio	38dB
usable sensitivity (loop)	425µV
distortion (1kHz, 50% mod)	1.0%
selectivity (±10kHz)	30dB

Video Specifications

television format	NTSC
input level/impedance	1Vp-p/75 ohms
output level/impedance	1Vp-p/75 ohms
video frequency response (composite video)	10Hz – 8MHz (–3dB)
HDMI support	up to 4K x 2K

General Specifications

power requirement	120V AC/60Hz
power consumption	<0.5W (standby); 450W maximum
dimensions (H x W x D)	4-3/4" x 17-5/16" x 11-13/16" (121mm x 440mm x 300mm)
weight	10lb (4.6kg)
