AVR 3600 TECHNICAL SPECIFICATIONS
ENGLISH
Audio Section
Stereo Mode, Continuous Average Power (FTC)
80 Watts per channel, 20Hz–20kHz, @ <0.07% THD,
both channels driven into 8 ohms
Seven-Channel Surround Modes
Power per Individual Channel
Front L & R channels:
80 Watts per channel
@ <0.07% THD, 20Hz–20kHz into 8 ohms
Center channel:
80 Watts @ <0.07% THD, 20Hz–20kHz into 8 ohms
Surround (L & R Side, L & R Back) channels:
80 Watts per channel
@ <0.07% THD, 20Hz–20kHz into 8 ohms
Input Sensitivity/Impedance
Linear (High-Level) 200mV/47k ohms
Signal-to-Noise Ratio (IHF-A) 100dB
Surround System Adjacent Channel Separation
Pro Logic
®
II 40dB
Dolby
®
Digital (AC-3) 55dB
DTS
®
55dB
Frequency Response
@ 1W (+0dB, –3dB) 10Hz –130kHz
High Instantaneous
Current Capability (HCC) ±35 Amps
Transient Intermodulation
Distortion (TIM) Unmeasurable
Slew Rate 40V/µsec
FM Tuner Section
Frequency Range 87.5–108.0MHz
Usable Sensitivity IHF 1.3µV/13.2dBf
Signal-to-Noise Ratio Mono/Stereo 70/68dB
Distortion Mono/Stereo 0.2/0.3%
Stereo Separation 40dB @ 1kHz
Selectivity ±400kHz, 70dB
Image Rejection 80dB
IF Rejection 90dB
AM Tuner Section
Frequency Range 520–1710kHz
Signal-to-Noise Ratio 45dB
Usable Sensitivity Loop 500µV
Distortion 1kHz, 50% Mod 0.8%
Selectivity ±10kHz, 30dB
Video Section
Television Format NTSC
Input Level/Impedance 1Vp-p/75 ohms
Output Level/Impedance 1Vp-p/75 ohms
Video Frequency Response
(Composite and S-Video) 10Hz–8MHz (–3dB)
Video Frequency Response
(Component Video) 10Hz–100MHz (–3dB)
HDMI
™
Version 1.3a with 10-bit Deep Color
General
Power Requirement AC 120V/60Hz
Power Consumption 890W maximum
(7 channels driven)
Stand-by consumption <1W
Dimensions (Product) (Shipping)
Width 17-5/16 inches (440mm) 21-7/8 inches (555mm)
Height 6-1/2 inches (165mm) 10-1/2 inches (266mm)
Depth 15 inches (382mm) 18-5/16 inches (465mm)
(Product) (Shipping)
Weight 27.3 lb (12.4kg) 32.1 lb (14.6kg)
Depth measurement includes knobs, buttons and terminal connections.
Height measurement includes feet and chassis.
Features, specifications and appearance are subject to change without notice.
Harman Kardon and Logic 7 are trademarks of Harman International Industries, Incorporated, registered in the
United States and/or other countries. EzSet/EQ, Designed to Entertain and The Bridge III logo are trademarks of
Harman International Industries, Incorporated.
iPod, iTunes and Apple are trademarks of Apple Inc., registered in the U.S. and other countries. iPhone is a trade-
mark of Apple Inc. iPod and iPhone not included. “Made for iPod” means that an electronic accessory has been
designed to connect specifically to iPod and has been certified by the developer to meet Apple performance stan-
dards. “Works with iPhone” means that an electronic accessory has been designed to connect specifically to iPhone
and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the
operation of this device or its compliance with safety and regulatory standards.
A-BUS is a registered trademark of Leisure Tech Electronics Pty Ltd.
Blu-ray Disc is a trademark of the Blu-ray Disc Association.
CEA is a registered trademark of the Consumer Electronics Association.
Cirrus Logic is a registered trademark of Cirrus Logic, Inc.
Manufactured under license from Dolby Laboratories. Dolby, Pro Logic and the double–D symbol are registered
trademarks of Dolby Laboratories. MLP Lossless is a trademark of Dolby Laboratories.
Manufactured under license under U.S. Patent #'s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,226,616;
6,487,535; 7,212,872; 7,333,929; 7,392,195; 7,272,567 and other U.S. and worldwide patents issued and pending.
DTS is a registered trademark and the DTS logos, Symbol, DTS-HD and DTS-HD Master Audio are trademarks of
DTS, Inc. (c) 1996-2008 DTS, Inc. All Rights Reserved.
Faroudja DCDi Cinema is a trademark of Genesis Microchip Inc.
HD-DVD is a trademark of the DVD Format/Logo Licensing Corporation (DVD FLLC).
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.
SACD is a trademark of Sony Corporation.
TiVo is a registered trademark of TiVo Inc.
SIRIUS and all related marks and logos are trademarks of Sirius XM Radio Inc. and its subsidiaries. All other marks
and logos are the property of their respective owners. All rights reserved. SIRIUS subscription sold separately. Taxes
and a one-time activation fee may apply. SIRIUS tuner required (sold separately) to receive the SIRIUS service. All
programming and fees subject to change. It is prohibited to copy, decompile, disassemble, reverse engineer, hack,
manipulate or otherwise make available any technology or software incorporated in receivers compatible with the
SIRIUS Satellite Radio System. Service not available in Alaska or Hawaii.
This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents
and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copy-
right protection technology must be authorized by Macrovision Corporation and is intended for home and other lim-
ited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or diassembly
is prohibited.
Please register your AVR 3600 at www.harmankardon.com.
You’ll need the product’s serial number. At the same time, you can
choose to be notified about new products and/or special promotions.
