Harman Kardon AVR 3600 Service Manual

AVR3600 Electrical Parts List
Ref. Designator Part Number Qty
FRONT PCB ASS'Y COP12168D
Capacitors
C121 CCBS1H151KBT CAP , CERAMIC(150PF/50V) CH UP025 B151K-A-B Z 1 EA
C122 CCEA1AH331T CAP , ELECT 330UF 10V 1 EA
C151 CCBS1H473ZFT CAP , CERAMIC(47000PF/50V) CH UP025 F473Z-A-B J 1 EA
C152 CCEA1CKS100T CAP , ELECT 10UF 16V 1 EA
C161 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C213 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1 EA
C214 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1 EA
C252 CCEA1HKS2R2T CAP , ELECT 2.2UF 50V SMALL SIZE 1 EA
C311 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) CH UP025 B102K-A-B Z 1 EA
C322 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) CH UP025 B102K-A-B Z 1 EA
C412 CCBS1H103ZFT CAP , CERAMIC 0.01UF 50V Z 1 EA
C413 CCEA1JH470TS CAP , ELECT 63V/47UF/105'C 1 EA
C414 CCEA1JH470TS CAP , ELECT 63V/47UF/105'C 1 EA
C415 CCBS1H103ZFT CAP , CERAMIC 0.01UF 50V Z 1 EA
C422 CCEA1HH4R7T CAP , ELECT 4.7UF 50V 1 EA
C431 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C441 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1 EA
C442 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1 EA
C503 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C504 CCBS1H103ZFT CAP , CERAMIC 0.01UF 50V Z 1 EA
C511 CCBS1H560JT CAP , CERAMIC(56PF/50V) CH UP025SL560J-A-B Z 1 EA
C512 CCBS1H560JT CAP , CERAMIC(56PF/50V) CH UP025SL560J-A-B Z 1 EA
C521 CCEA1AH101T CAP , ELECT 100UF 10V 1 EA
C522 CCBS1H103ZFT CAP , CERAMIC 0.01UF 50V Z 1 EA
C531 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C533 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C541 CCBS1H101KBT CAP , CERAMIC(100PF/50V) CH UP025 B101K-A-B Z 1 EA
C542 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C553 CCBS1H101KBT CAP , CERAMIC(100PF/50V) CH UP025 B101K-A-B Z 1 EA
C554 CCBS1H101KBT CAP , CERAMIC(100PF/50V) CH UP025 B101K-A-B Z 1 EA
C601 CCBS1H181KBT CAP , CERAMIC(180PF/50V) CH UP025 B181K-A-B Z 1 EA
C602 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C603 CCBS1H100JCT CAP , CERAMIC(10PF/50V) CH UP025CH100J-A-B Z 1 EA
C611 CCEA1AH471T CAP , ELECT 470UF 10V 1 EA
C612 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C631 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C633 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C651 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C652 CCBS1H471KBT CAP , CERAMIC(470PF/50V) CH UP025 B471K-A-B Z 1 EA
C653 CCBS1H471KBT CAP , CERAMIC(470PF/50V) CH UP025 B471K-A-B Z 1 EA
C714 CCBS1H223ZFT CAP , CERAMIC(22000PF/50V) CH UP025 F223Z-A-B J 1 EA
C715 CCEA1CKS100T CAP , ELECT 10UF 16V 1 EA
C721 CCEA1HKS2R2T CAP , ELECT 2.2UF 50V SMALL SIZE 1 EA
C731 CCEA1AH471T CAP , ELECT 470UF 10V 1 EA
C732 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C751 CCBS1C222MXT CAP , CERAMIC(2200PF/16V) CH EP025 B222M-A-B J 1 EA
C752 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) CH UP025 B102K-A-B Z 1 EA
C753 CCBS1H102KBT CAP , CERAMIC(1000PF/50V) CH UP025 B102K-A-B Z 1 EA
C754 CCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z 1 EA
C801 CCEA1EH470T CAP , ELECT 47UF 25V 1 EA
C802 CCEA1EH470T CAP , ELECT 47UF 25V 1 EA
C811 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C813 CCBS1H470JT CAP , CERAMIC(47PF/50V) CH UP025SL470J-A-B Z 1 EA
C821 CCBS1H471KBT CAP , CERAMIC(470PF/50V) CH UP025 B471K-A-B Z 1 EA
C822 CCBS1H151KBT CAP , CERAMIC(150PF/50V) CH UP025 B151K-A-B Z 1 EA
C823 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C830 CCBS1H473ZFT CAP , CERAMIC(47000PF/50V) CH UP025 F473Z-A-B J 1 EA
C901 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C902 CCEA1HH100T CAP , ELECT 10UF 50V 1 EA
C911 CCEA1EH470T CAP , ELECT 47UF 25V 1 EA
Description
AVR3600 harman/kardon
40
