TECHNICAL SPECIFICATIONS 65
ENGLISH
Technical Specifications
Audio Section
Stereo Mode
Continuous Average Power (FTC)
80 Watts per channel, 20 Hz–20 kHz,
@ < 0.07% THD, both channels driven into 8 ohms
5/7 Channel Surround Modes
Power Per Individual Channel
Front L&R channels:
65 Watts per channel,
@ < 0.07% THD, 20 Hz–20 kHz into 8 ohms
Center channel:
65 Watts, @ < 0.07% THD, 20 Hz–20 kHz into 8 ohms
Surround (L & R Side, L & R Back) channels:
65 Watts per channel,
@ < 0.07% THD, 20 Hz–20 kHz into 8 ohms
Input Sensitivity/Impedance
Linear (High Level) 200mV/47kohms
Signal-to-Noise Ratio (IHF-A) 95 dB
Surround System Adjacent Channel Separation
Analog Decoding 40 dB
(Pro Logic, etc.)
Dolby Digital (AC-3) 55 dB
DTS 55 dB
Frequency Response
@ 1W (+0 dB, –3 dB) 10 Hz–130 kHz
High Instantaneous
Current Capability (HCC) ±40 Amps
Transient Intermodulation
Distortion (TIM) Unmeasurable
Rise Time 16 µsec
Slew Rate 40V/µsec**
FM Tuner Section
Frequency Range 87.5–108 MHz
Usable Sensitivity IHF 1.3 µV/13.2 dBf
Signal-to-Noise Ratio Mono/Stereo: 70/68 dB (DIN)
Distortion Mono/Stereo: 0.15/0.2%
Stereo Separation 40 dB @ 1 kHz
Selectivity ±400 kHz: 70 dB
Image Rejection 80 dB
IF Rejection 90 dB
AM Tuner Section
Frequency Range 520–1710 kHz
Signal-to-Noise Ratio 45 dB
Usable Sensitivity Loop: 500µV
Distortion 1 kHz, 50% Mod: 0.8%
Selectivity ±10 kHz: 30 dB
Video Section
Video Format PAL/NTSC
Input Level/Impedance 1Vp-p/75 ohms
Output Level/Impedance 1Vp-p/75 ohms
Video Frequency Response
(Composite and S-Video) 10 Hz–8 MHz (–3 dB)
Video Frequency
Response (Component) 10 Hz-50 MHz (–3 dB)
HDMI Version 1.1
General
Power Requirement AC 220-240 V/50 Hz
Power Consumption 120 W idle, 1180 W maximum
(7 channels driven)
Dimensions (Max)
Width 440 mm
Height 165 mm
Depth 435 mm
Weight 17.7 kg
Depth measurement includes knobs, buttons and terminal connections. Height measurement
includes feet and chassis.All features and specifications are subject to change without notice.
Harman Kardon and Power for the Digital Revolution are registered trademarks of
Harman International Industries, Incorporated.
and are trademarks of Harman International Industries, Incorporated.
(Patent No. 5,386,478).
*Manufactured under license from Dolby Laboratories.
“Dolby,” “Pro Logic,” “Pro Logic II,” "Pro Logix IIx" and the Double-D symbol are trademarks of
Dolby Laboratories. Confidential Unpublished Works. ©1992–1999 Dolby Laboratories, Inc.
All rights reserved.
DTS and DTS Surround, DTS-ES and DTS Neo:6 are trademarks of Digital Theater Systems, Inc.
Logic 7 is a registered trademark of Harman International Industries, Incorporated.
A-BUS and A-BUS/
READY
®
Ready are registered trademarks of Leisure Tech Electronics Pty Ltd
Australia.
TiVo is a registered trademark of TiVo, Inc.
SACD is a trademark of Sony Corporation.
iPod is a registered trademark of Apple Computer, Inc.
DLP and Texas Instruments are trademarks of Texas Instruments.
HD-DVD is a trademark of the DVD Format/Logo Licensing Corporation (DVD FLLC).
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing, LLC.
Microsoft, Windows and Windows Media are registered trademarks of Microsoft Corporation in
the United States and other countries.
**Without input anti slewing and output isolation networks.
