Club 8" speaker
225mm
(8-7/8")
170mm
(6-11/16")
83.7mm
(3-5/16")
112.3mm
(4-7/16")
Club 10" speaker
273mm
(10-3/4")
221.5mm
(8-3/4")
127.5mm
(5-1/16")
169.5mm
(6-3/4")
Club 12" speaker
325mm
(12-13/16")
280mm
(11-1/16")
154.5mm
(6-1/16")
198.5mm
(7-13/16")
SPEAKER SIGNAL WIRING
To send signal to the JBL marine speaker, connect the positive (+)
and negative (-) speaker wires to the appropriate speaker outputs
of your source unit or amplifier. Be sure to observe proper polarity.
+
+
RGB
THANK YOU FOR YOUR PURCHASE ...
Your JBL product has been designed to provide you with the
performance and ease of operation you would expect from JBL.
ABOUT THE MANUAL
This manual describes general installation guidelines. However,
please note that proper installation of marine audio components
requires qualified experience. If you do not have the knowledge
and tools to successfully perform this installation, we strongly
recommend consulting an authorized JBL dealer about your
installation options. Keep all instructions and sales receipts for
reference.
WHAT’S IN THE BOX
Club 6.5" and 8" speakers
12X
12X
2X
2X
1X
2X
4X
2X
2X
1X
Club 10" and 12" speakers
6X
6X
1X
1X
1X
2X
2X
1X
1X
1X
DIMENSIONS
Club 6.5" speaker
178mm
(7-1/64")
133mm
(5-1/4")
91mm
(3-19/32")
65mm
(2-9/16")
JBL Club 6.5", 8", 10", and 12"
Marine Speaker
CA_JBL Club Marine Speakers_OM_Global_SOP_V9.indd 2CA_JBL Club Marine Speakers_OM_Global_SOP_V9.indd 2 6/17/2022 4:21:26 PM6/17/2022 4:21:26 PM
