2.2: PARTS OF THE CONSOLE
GETTING STARTED > PARTS OF THE CONSOLE
2.2: Parts Of The Console
NOTEPAD 5, 8FX, 12FX 8VHU0DQXDO
);5HWXUQ1RWHSDG);RQO\
7KH);UHWXUQFKDQQHOWDNHVLWVLQSXWIURPWKHRXWSXWRIWKHLQWHUQDO/H[LFRQ);SURFHVVRU
• ,WLVDVWHUHRLQSXWFKDQQHOEXWZLWKRXWLQSXWWULPFRQWURORU(4
• 7ZRMDFNLQSXWVDUHSURYLGHGZKLFKZKHQDMDFNLVSOXJJHGLQUHSODFHWKHLQWHUQDOHIIHFWVURXWLQJWRWKH
FX return channel.
Refer to Sections 4.3 and 5.1.3 for more detail.
$X[2XWSXW1RWHSDG);DQG);
The Aux output signal is derived frovm a mix of all the contributing channel Aux/FX send controls.
Refer to Sections 4.4 and 5.2 for more detail.
0RQLWRU2XWSXW1RWHSDGRQO\
Aux (Auxiliary) Master output channels control the output level of the auxiliary bus and global pre-fade/
post-fader switching. AFL switching allows aux master solos.
Refer to Sections 4.5 and 5.4 for more detail.
0DVWHU6WHUHR2XWSXW
Controls the output level of the Master Stereo bus.
Refer to Sections 4.6 and 5.4 for more detail.
Metering
The meters on the Notepad show Master Left/Right output level.
Refer to section 5.4 and 6.0 for more detail.
/H[LFRQ);&RQWURO
Notepad-8FX and -12FX consoles have an internal Lexicon FX processor and send bus for adding effects
such as reverb, chorus and delay. Each effect has a parameter adjustment affecting one or more features
of the effect.
Refer to section 8.0 for more detail.
*OREDO3KDQWRP3RZHU
48V phantom power is always active on each of the console microphone inputs so you can use Condens-
er/Capacitor microphones, active DI boxes, and other devices requiring phantom power. See section 5.1.1
for more detail.
+HDGSKRQH/HYHO&RQWURO
Level control for the monitoring output - either the Master Stereo Output, or the Aux Bus. See section 6.0
for more detail.
