2. Description of engine

1D41 • 1D50 • 1D81 • 1D90 S / Z engines

2391 / 12 2391 / 7

1 Cooling air inlet

2 Dry-type air cleaner

3 Decompression lever

4 Stop lever

5 Cooling air outlet

6 Silencer (muffler)

7 Guide sleeve for starting handle

8 Cylinder head cover

9 Cold-start oil metering device

10 Suspension lug

11 Tank filler cap

12 Oil drain plug, governor housing

13 Oil drain plug, governor side

14 Speed control lever

15 Oil filler pipe and dipstick

16 Fuel filter

17 Oil filter

18 Type plate

19 Tank drain plug

20 Combustion air intake
