2L41C, 2M41, 2M41Z Maintenance
HATZ
61Operator’s Manual
Draining the oil
Step Activity
1 Unscrew the oil drain screw (1) and drain the oil entirely.
When unscrewing the oil drain screw (1) on engines of type
2L41C, ensure that the drain pipe (2) is not loosened. Hold it
with an open-end wrench.
2 Screw in the cleaned oil drain screw (1) with the new gasket
and tighten.
Overview — Checking oil level/adding oil
1 Dipstick
2 Code letter on the dipstick
Procedure — Adding oil
Step Activity
1 Add engine oil to the max. mark on the dipstick(1).
▪ For the specification and viscosity, see chapter 4.4 Engine
oil, page 24.
▪ The code letter on the dipstick (2) indicates whether the en-
gine is equipped with an oil sump or not (see chapter 4
Technical data, page 21).
2 Reinsert the dipstick (1).
3 After a short test run, check the oil level and correct it if neces-
sary (see the chapter 7.8 Check the oil level, page 49).
