2L41C, 2M41, 2M41Z Engine design
HATZ
27Operator’s Manual
Pos. Designation
15 Capsule intake shaft
16 Intake opening for combustion air
17 Fuel feed line with fuel prefilter
18 Fuel return line
19 Cover plate on exhaust side
20 Central connector for electrical equipment
21 Battery connections
22 Powerbox
23 Electrical maintenance switch for air filter
Engine 2M41, 2M41Z
Standard model
Pos. Designation
1 Oil filling opening and dipstick
2 Side trim panel
3 Intake opening for combustion air
4 Cooling fan belt
5 Cooling fan with installed three phase alternator

Hatz 2M41 Specifications

General

Number of Cylinders	2
Cooling System	Air-cooled
Fuel System	Direct injection
Compression Ratio	17.5:1
Engine Type	Diesel
Starting System	Electric starter
