1 Intake opening for combustion air
2 Rain cap
3 Air filter (optional)
4 Dust discharge valve
5 Lifting eyes
6 Fan
7 Oil filter
8 Fuel fine filter
9 Side oil drain screw
10 Starter (low mounting position)
11 Electric fuel pump
12 Drain plug on fuel prefilter
13 Fuel prefilter
14 Engine type plate
15 Dipstick
16 Oil filler plug, bottom
17 Crankcase ventilation
4H50TIC Engine design
HATZ
Operator's Manual 29
