Hatz 4H50TIC User Manual

8.2.10 Checking the screw connections
Safety note
NOTICE
i
▪ Only retighten loose screw connections.
Screw connections can be secured with thread locking ad-
hesive or tightened to a defined torque. Retightening tight
screw connections can cause damage.
▪ The adjustment screws on the injection system are secured
with locking varnish and are not permitted to be tightened or
adjusted.
▪ Do not retighten the screws for attaching the cylinder head.
Overview
1
2
3
1 Engine base mounting bolts
2 Vibration damper mounting bolt
3 Chassis frame mounting bolts
Procedure
Step Activity
1 Check the mounting bolts of the engine mountings (4x) and
tighten if needed.
2 Check the condition of all remaining screw connections and
ensure that they are tight (for exceptions, see note).
3 Tighten any lose screw connections.
Maintenance 4H50TIC
72 Operator's Manual
HATZ
