6 Transport, assembly and commissioning
6.1 Transport - Engine with 2 lifting eyes
Safety notes
WARNING
Danger of injury from improper lifting and transport.
Danger of crushing from falling or tipping of the engine.
▪ Only use the lifting eye already mounted on the machine for
lifting.
▪ Only use a suitable hoist with a sufficient carrying capacity.
▪ Do not remain under suspended loads.
CAUTION
Only use lifting lugs for transporting the engine.
Do not use for lifting the entire machine.
CAUTION
Danger of injury from overloading the body.
Lifting the machine to transport it or to move it to another loca-
tion can lead to injuries (of the back, for example).
▪ Only lift the machine with a hoist.
NOTICE
Danger of environmental damage from leaking fluid.
If the machine is tilted, engine oil and fuel can run out.
▪ Only transport the machine in an upright position.
4H50TIC Transport, assembly and commissioning
HATZ
Operator's Manual 31
