Safety note
CAUTION
Danger of later engine damage.
▪ Operating the engine with an oil level below the min. mark
or above the max. mark can lead to engine damage.
▪ When checking the oil level, the engine must be horizontal
and have been switched off for a few minutes.
Overview
1 Dipstick
2 Oil filler plug, top
3 Oil refilling container
4 Oil filler plug, bottom
Procedure
Step Activity
1 Pull out the dipstick (1) and clean it.
Transport, assembly and commissioning 4H50TIC
34 Operator's Manual
