Overview — HATZ instrument boxes
2
I
0
2
1
Pos. Designation
1 Starting key
2 Protective cap
Ignition lock
0 Off
I Operation
Procedure
Step Activity
1 Turn the starting key (1) to position "0".
The engine switches off.
All indicator lamps go out.
2 Remove the starting key.
3 Seal the ignition lock with the protective cap (2).
Operation and use 4H50TIC
46 Operator's Manual
