Overview
1 Dipstick
2 Oil filler plug, top
3 Oil refilling container
4 Oil filler plug, bottom
Procedure — Checking oil level/adding oil
Step Activity
1 Switch off the engine and wait several minutes for the engine oil
to collect in the crank housing. Engine must be level.
2 Remove contamination on the engine in the area of the dipstick
(1).
3 Pull out the dipstick and clean it.
4 Reinsert the dipstick.
5 Pull out the dipstick and check the oil level.
Operation and use 4H50TIC
48 Operator's Manual
HATZ
