Overview
1
2 3
5
4
6
7
1 Alternator mounting bolt
2 Bracket
3 Belt tensioner
4 Hex nut
5 Clamping claw
6 Torque wrench with dial gage display
7 Measurement point for frequency measurement
Procedure
Step Activity
1 Check the poly v belt for wear. Do not retension a worn poly v
belt, but immediately replace it.
Maintenance 4H50TIC
