Hayward H210 User Manual

40
SECTION 7. TROUBLESHOOTING
1. HAXJKT1150 Jacket Top Asy. -150
1. HAXJKT1200 Jacket Top Asy. - 200
1. HAXJKT1251 Jacket Top Asy. - 210/250
1. HAXJKT1301 Jacket Top Asy. - 300
1. HAXJKT1351 Jacket Top Asy. - 350
1. HAXJKT1401 Jacket Top Asy. - 400
2. HAXDH01930 DHO Insert
3. DHI150 Indoor Drafthood -150
3. DHI200 Indoor Drafthood - 200
3. DHI250 Indoor Drafthood - 250
3. DHI300 Indoor Drafthood - 300
3. DHI350 Indoor Drafthood - 350
3. DHI400 Indoor Drafthood - 400
3. HWS150 High Wind Stack -150 (Not Shown)
3. HWS200 High Wind Stack - 200 (Not Shown)
3. HWS250 High Wind Stack - 210/250 (Not Shown)
3. HWS300 High Wind Stack - 300 (Not Shown)
3. HWS350 High Wind Stack - 350 (Not Shown)
3. HWS400 High Wind Stack - 400 (Not Shown)
4. HAXHXA1150 Heat Exchanger Asy. -150
4. HAXHXA1200 Heat Exchanger Asy. - 200
4. HAXHXA1210 Heat Exchanger Asy. - 210
4. HAXHXA1250 Heat Exchanger Asy. - 250
4. HAXHXA1300 Heat Exchanger Asy. - 300
4. HAXHXA1350 Heat Exchanger Asy. - 350
4. HAXHXA1400 Heat Exchanger Asy. - 400
5. HAXWHA0006 Rear Wire Harness, MV
6. HAXF0R1930 O-Rings
7. HAXNIP1930 Flange Pipe Nipples
8. HAXNUT1930 Union Nuts
10. HAXFCT1930 Flow Control Thermostat
11. CHXPLG1930 3/4” NPT Brass Plug
12. HAXBPK1932 By Pass Valve Kit
16. HAXHLI1930 Hi-Limit 135° F
17. HMXHLI2932 Hi-Limit 160° F
18. CHXDRV1930 Drain Valve Asy.
19. CHXPSA1930 Pressure Switch Adapter
Parts List - Millivolt
20. HAXTBW1930 Bulb Well
21 HAXFHA1931 Front Header Asy.
22. HAXLAC1930 Left Access Cover
23. HAXURA1930 Upper Right Access Cover
24. HAXLRA1931 Lower Right Access Cover
25. HAXPHK1930 Plastic Hardware Kit
26. HAXTLK1930 Temperature Limiters Kit
27. HAXTBK1931 2-Pole Terminal Block
28. HAXPLG1931 3/8" Brass Plug
29. CHXGRL1930 TA-2 Ground Lug
32. HAXPSA1930 Pressure Switch Asy.
33. CHXTST1930 Thermostat
35. CHXTSW1930 System Switch Single
36. HAXCPA2150 Control Panel Asy. -150 MV
36. HAXCPA2200 Control Panel Asy. - 200 MV
36. HAXCPA2250 Control Panel Asy. - 210/250 MV
36. HAXCPA2300 Control Panel Asy. - 300 MV
36. HAXCPA2350 Control Panel Asy. - 350 MV
36. HAXCPA2400 Control Panel Asy. - 400 MV
37. HAXGSV0001 Gas Valve, MV Natural Gas
37. HAXGSV0003 Gas Valve, MV Propane
38. HAXMAN1150 Gas Manifold -150
38. HAXMAN1200 Gas Manifold - 200
38. HAXMAN1250 Gas Manifold - 210/250
38. HAXMAN1300 Gas Manifold - 300
38. HAXMAN1350 Gas Manifold - 350
38. HAXMAN1400 Gas Manifold - 400
39. HAXBRN1930 Burner Tube
40. HAXB0N1930 Burner Orice Natural Gas
40. HAXBON1931 Burner Orice Natural Gas HA
40. HAXBOP1932 Burner Orice Propane
40. HAXBOP1931 Burner Orice Propane HA
44. HAXPLT1931 Pilot Natural Gas
44. HAXPLT1932 Pilot Propane
45. HAXTRK1930 Pilot Tube Replacement Kit
46. HAXHOR1930 Header O-Ring
48. HAXPLG1931 1/4” Brass Plug
49. HAXCIA1930 Corner Piece Kit (4)
HAXWHA0001 Wire Harness Main MV (not shown)
ITEM NO. ITEM NO.PART NO. PART NO.DESCRIPTION DESCRIPTION

Hayward H210 Specifications

General

Brand	Hayward
Model	H210
Category	Swimming Pool Heater
Language	English
