HELLER HPAC10 User Manual

• Never immerse the appliance in water or any other liquid.
Special Recommendations
• Ensure that the appliance is positioned on a flat, large, dry surface without any obstacles nearby. A
minimum distance from furniture and walls is 50cm in all directions.
• The plug should be easily accessible.
• In order to maintain the function of the compressor, the appliance should always be in a vertical
position.
• Do not use the appliance near gas or other flammable liquids.
• Do not block the air outlet or the air inlet ventilation.
• Do not use spray (insecticides, paint) or any other flammable products near the appliance as the
plastic may become deformed. The unit may also sustain electrical damage.
Power Source
• The plug should be well secured and not damaged.
• Do not plug in the appliance with an adaptor.
• Plug into the wall socket before switching on the appliance, and then press the ON/OFF button.
THE MANUFACTURER WILL NOT ASSUME ANY RESPONSIBILITY FOR NON COMPLIANCE OF INSTRUCTIONS.
KEEP THIS USER MANUAL FOR FUTURE REFERENCE.
Installation
Location
Place the unit on a flat, dry surface. Leave at least 50cm of space around the unit, as per below diagram 1.
DIA 1
50cm

HELLER HPAC10 Specifications

Operating Environment

permissible excessive operating pressure (suction)	1.5 MPa
permissible excessive operating pressure (discharge)	5.5 MPa
maximum allowable pressure (low pressure side)	1.7 MPa
maximum allowable pressure (high pressure side)	5.5 MPa

Power

power supply	220-240 V / 50 Hz
rated input (cooling)	1050 W

Performance

cooling capacity	2.93 kW
air flow	360 m3/h
noise	55 dB(A)

Refrigerant

refrigerant type	R410a
refrigerant charge	500 g

Weight and Dimensions

net weight	25 kg
gross weight	30 kg
dimensions (WxHxD)	433 x 795 x 330 mm
