HELLER HPAC10 User Manual

Operation
Cooling mode
1. After operating the machine press the Mode button to choose Cool mode, the Cool mode indicator
will flash.
2. Press the UP or DOWN button to set room temperature between 17℃ to 30℃.
3. Press FAN SPEED button (or High/Low button) to select high/low fan speed.
Fan mode
1. Press Fan button to choose Fan mode, the Fan mode indicator will flash.
2. Select the fan speed by pressing the SPEED button or press High / Low button directly.
3. This is a fan only function, the temperature cannot be set.
Automatic temp mode
1. Press the Mode button to choose the automatic setting. The automatic mode indicator light will flash.
After choosing the automatic mode, the unit running temperature will depend on the actual room
temperature. When the room temperature is higher than 25°, the unit will go into cool mode. You can
select the fan speed mode and timer mode when it is in automatic mode.
Sleep Mode (Optional Function)
1. Press this button to activate or cancel the sleep function in cooling mode. The unit will run at the low fan
speed as a default and with lower noise. The setting temperature will increase 1 degree per 2 hours
running time, and it will only increase by a maximum 2 degrees.
Max cool Mode (Optional Function)
1. Press this button to activate the Max cool mode. The unit runs cool but is not restricted by the
temperature setting of the Max cool mode. The unit is locked in high fan speed under this mode, and the
fan speed cannot be adjusted.
Timer mode
1. When the appliance is switched off, press the Timer button to set timer-on.
2. Press the Up or Down button to adjust the time from 0 to 24 hours. The Timer on indicator light will
flash.
3. When the appliance is running, press Timer button to set timer-off.
4. Press the Up or Down button to adjust time from 0 to 24 hours. The Timer off indicator will flash.
Water Drainage
This product has a self-evaporative system. The water will be recycled to cool the condenser. This not only
improves cooling efficiency, but also saves energy.
• Under certain circumstances if the inside water container is full, the display panel will display “FL”, and
the compressor will stop running.
• Please turn the machine off, and move the machine to a place where the inbuilt water tank can drain,
and then unplug the water-draining hole to let all of the water out of the tank.
• After drainage, you can power it on and the machine will run again (Gravity drain only).

HELLER HPAC10 Specifications

Operating Environment

permissible excessive operating pressure (suction)	1.5 MPa
permissible excessive operating pressure (discharge)	5.5 MPa
maximum allowable pressure (low pressure side)	1.7 MPa
maximum allowable pressure (high pressure side)	5.5 MPa

Power

power supply	220-240 V / 50 Hz
rated input (cooling)	1050 W

Performance

cooling capacity	2.93 kW
air flow	360 m3/h
noise	55 dB(A)

Refrigerant

refrigerant type	R410a
refrigerant charge	500 g

Weight and Dimensions

net weight	25 kg
gross weight	30 kg
dimensions (WxHxD)	433 x 795 x 330 mm
