2.14. Safety distances
1900
60
mm
mm
60
770
60
60
40 *)
OLET 28
425 mm
1130
OLET 28
1900
60
mm
60
770
OLET 28
OLET 28
AD
F
H
A
A
F
H
*)
*)
Installation and User Manual ROCHER DET
11
Corner and wall installation
Fixing the sauna heater
on the floor. NOTE fixing
of two (2) legs
Absolute measurement! (must not be exceeded
or undershot)
Adjustable
leg
Floor
fastener
Hearters leg
Metal fastener
Safety clearances between the bottom of the sauna
heater and a wall.
NOTE! If the sauna heater is installed further
than 60mm off a wall or a corner, the installation
method is always middle installation. The thermostat
must be installed in the ceiling, as per instructions.
NOTE! All the dimensions are minimum
dimensions unless otherwise mentioned.
Middle installation:
Image 5
Image 6
