User Manual of DS-1005KI Keyboard
11
Operating PTZ Control 3.2.2
You can use the keyboard to control PTZ, call preset, patrol and pattern in the live view under USB
joystick mode.
Open the iVMS-5200 Control Client. Step 1
Go to Control Panel>Main View. Step 2
Double-click the camera from the device list or drag it to the window to start playing the live Step 3
video.
You can access the Web Client of iVMS-5200 (Video Surveillance>Video Management>Physical
View) to add the devices. Refer to the User Manual of iVMS-5200 Professional Web Client for
details.
Operate the PTZ control via USB joystick. Step 4
 Move the keyboard joystick to control the PTZ movement of the camera (which supports
PTZ function).
 Rotate the joystick in clockwise/anticlockwise to realize zoom in/out.
 Press the left button at the joystick top to capture the picture.
 Press the right button at the joystick top to start recording for the camera.
PTZ Control Figure 3-2

HIKVISION DS-1005KI Specifications

General

Type	Joystick
Product color	Black, Silver
Placement supported	Universal
Programmable buttons	Yes
Number of joystick axis	3
Number of programmable buttons	15
Connectivity technology	Wired
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	5 V
Harmonized System (HS) code	85299020

Weight and Dimensions

Depth	177.5 mm
Width	167 mm
Height	116 mm
