User Manual of DS-1005KI Keyboard
15
The input numeric can be a 4-digit number at most;
The input numeric in range of 1-99 indicates the number of the selected window.
When you want to switch the sub-window, you can input a 3-digit or 4-digit numeric, in
which the last two numbers indicates the sub-window number. Example: if the input
numeric is 101, you switch to the sub-window 1 of window 1; and if the input numeric is
1112, you switch to the sub-window 12 of window 11.
Operate the PTZ control via USB joystick. Refer to the 3.4
Step 4 of Chapter 3.2 USB Joystick Mode
Under USB joystick mode, you can use the keyboard to control PTZ, call preset, patrol and pattern
in the live view interface.
Setting USB Joystick Mode 3.4.1
On the operation panel of the keyboard, press and hold the Window/Channel ( ) button for 5s
until the two indicators both light to switch to the USB joystick mode.
Operating PTZ Control for the same instructions. Step 1
Setting Files Saving Directory 3.5
You can set the saving directory of the recorded video files and captured pictures during the live
view or video wall control. You can also configure the FTP settings which can be used for saving the
manual recording and pictures to the FTP server.
Open the iVMS-5200 Control Client Software. Step 1
Go to Control Panel> Local Configuration. Step 2
Click the File tab to enter the File Saving Path Settings interface. Step 3
Click the icon and select a local path for the corresponding files. Step 4
Saving Path of Video File: The video file refers to the manual recording files during live view,
the clipped video during playback, the downloaded video files during playback and the video
files downloaded on Download Center page.
Saving Path of Pictures: The pictures refer to the captured pictures during live view and
playback.
For FTP settings, enter the IP address, port No., the login user name and password of the FTP Step 5
server, set a saving path for the uploaded pictures and video files.
