HIKVISION DS-2AE4215T-D User Manual

HD-TVI Speed Dome User Manual
9
information shown after the power-up action. Please refer to Section 2.1 for more details.
Enter the system information display menu:
MAIN MENUS > SYS INFO
SYS INFO
XXXXX
ADDRESS 0
COM MODE 2400.8.1
PROTOCOL AUTO MATCH
FIRMWARE 3.50
HARDWARE 1.00
BUILD DATE 19 01 17
BACK EXIT
SYS INFO
CAM VERSION 3.23-680
PARAM DATE 0 0 0
TEMPERATURE 30
VIDEO OUT TVI
BACK EXIT
Figure 3-3 System Information
 Information on this menu cannot be edited.
 The temperature refers to the internal temperature of the speed dome.
3.2.2 Configuring System Parameters
Purpose:
You can check and also edit the system information of software address, baud rate, system time, etc.
on the system information settings menu.
MAIN MENUS > SYS SETTINGS > SYSTEM INFO SETTING
SYS INFO SETTING
SOFT ADDRESS 1
SOFT ADDR ACT OFF
SOFT BAUD 2400
SOFT BAUD ACT OFF
BROADCAST ADDR ON
PELCO CHECKSUM ON
SYS TIME
BACK EXIT
SYS INFO SETTING
ZERO ANGLE
<DISPLAY SETTINGS>
HEAT CONTROL TEMP
FAN CONTROL TEMP
EIS FUNCTION OFF
EIS LEVEL N/A
PRESET FOCUS OFF
BACK EXIT
SYS INFO SETTING
PROTOCOL STATUS OFF
PROTOCOL AUTO MATCH
485 CHECK AUTO
POWER MEMORY 180S
NEAR FOCUS LEVEL 1
COAXITION ACT ON
PROTOCOL-C AUTO
BACK EXIT
Figure 3-4 System Information Settings
You can click the left and right direction buttons in the PTZ control panel via the web browser of
the encoder to enter the next page and return to the previous page of the submenu if more
than one page is available.

HIKVISION DS-2AE4215T-D Specifications

General

Brand	HIKVISION
Model	DS-2AE4215T-D
Category	Security Camera
Language	English
