HD-TVI Speed Dome User Manual
21
 Set the electricity level of the IR LED.
The N/M LED CURRENT and the FAR LED CURRENT refer to the electricity level of the
near/middle IR LED and far IR LED correspondingly.
 Set the parameters for reference zoom.
The value of REFERENCE ZOOM can be adjusted from 2 to 10.
 Set the parameters of LED control.
LED control can be set to ALL ON (enable all the IR LED), FAR ON (enable far-distance IR LED),
NEAR ON (enable near/medium-distance IR LED), AUTO (enable IR LED automatically according
to the environment illumination), ICR (adjust the IR LED working mode according to the ICR),
and CLOSE (disable IR LED).
 Set the IR LED switch delay.
The SWITCH DELAY(S) refers to the delay time between the switch of far-distance IR LED and
N/M-distance IR LED.
 Set smart IR.
The brightness of IR automatically changes according to the focal length. The greater the value,
the more obvious the brightness changed.
3.4 Configuring PTZ Control Parameters
Purpose:
You can adjust panning, tilting and zooming movements, and also PTZ control functions including
presets, patrols, patterns, etc. of the speed dome.
3.4.1 Configuring PTZ Parameters
Enter PTZ configuration menu:
MAIN MENUS > SYS SETTINGS > MOTION PARAMETER
MOTION
AUTO FLIP ON
PROPORTIONAL PAN ON
PARK TIME 5
PARK ACT NONE
SCAN SPEED 28
IMAGE FREEZE OFF
MOVE SPEED 6
BACK EXIT
MOTION
PRESET SPEED 4
LIMIT STOP OFF
SETTING STOPS
CLEAR STOPS
ELEVATION SET ON
BACK EXIT
Figure 3-11 PTZ Configuration
 Auto-flip
In manual tracking mode, when a target object goes directly beneath the speed dome, the speed
dome automatically rotates 180 degrees horizontally for tracking.
AUTO-FLIP is set to ON by defaulted and it is not user-definable.
