Network Bullet Camera·Quick Start Guide
28
STRONG PASSWORD RECOMMENDED– We highly
recommend you create a strong password of your own
choosing (using a minimum of 8 characters, including
upper case letters, lower case letters, numbers, and
special characters) in order to increase the security of
your product. And we recommend you reset your
password regularly, especially in the high security
system, resetting the password monthly or weekly can
better protect your product.
Note:
You can enable the Hik-Connect service for the device during
activation. Refer to Chapter 5.1 for detailed information.
4. Click Activate to start activation.
You can check whether the activation is completed on the popup
window. If activation failed, make sure that the password meets
the requirement and try again.
Modifying the IP Address
Purpose:
To view and configure the camera via LAN (Local Area Network), you
need to connect the network camera in the same subnet with your
PC.
Use the SADP software or client software to search and change the
IP address of the device. We take modifying the IP Address via SADP
software as an example to introduce the IP address modification.
For IP address modification via client software, refer to the user
manual of client software.

HIKVISION DS-2CD1023G0-IU Specifications

General

Type	IP security camera
Placement supported	-
Connectivity technology	Wired
Wide Dynamic Range (WDR)	Yes
Bluetooth	No
Number of users	32 user(s)
Networking standards	IEEE 802.3af
Supported network protocols	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, IGMP, QoS, UDP
Ethernet LAN (RJ-45) ports	1
Form factor	Bullet
Mounting type	Ceiling/wall
Product color	Black, White
Housing material	Metal, Plastic
International Protection (IP) code	IP66
LED type	IR
Infra-red wavelength	850 nm
Night vision distance	30 m
Pan range	0 - 360 °
Tilt angle range	0 - 180 °
Angle of rotation	360 °
Camera shutter speed	1 - 1/100000 s
Minimum illumination	0.028 lx
Sensor type	CMOS
Optical sensor size	1/2.7 \
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	3.6 W
Power consumption (Power over Ethernet (PoE))	4 W
Fixed focal length	2.8 mm
Maximum aperture number	2
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 95 %
Total megapixels	2 MP
Maximum resolution	1920 x 1080 pixels
Image quality adjustment	Brightness, Contrast, Saturation, Sharpness
Video compression formats	H.264, H.265, M-JPEG
Noise reduction technology	3D noise reduction

Weight and Dimensions

Depth	66.2 mm
Width	67.8 mm
Height	177.6 mm
Weight	270 g
Package depth	121 mm
Package width	216 mm
Package height	118 mm
Package weight	470 g
